Metal Floor Decking Roll Forming Machine

₹ 39.82 Lakh / Set

MOQ1 Set(s)
Brand NameBelieve Industry
Production Capacity60 sets per quarter
Total Carbohydrate2 years for all the parts of the machine
After-Sales Service ProvidedCommission and Installation: Free
Place of OriginJIANG SU
Supply TypeManufacturer, Exporter
Preferred Buyer Location All over the world

Company Information

Member Since 9 Years
Nature of Business Manufacturer
Year of Establishment 2001

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Brand NameBelieve Industry
Production Capacity60 sets per quarter
Total Carbohydrate2 years for all the parts of the machine
After-Sales Service ProvidedCommission and Installation: Free
Place of OriginJIANG SU

Description:
this metal floor decking roll forming machine is used to produce metal floor decks. Main components of this machine are decoiler, guiding and leveling device, roll former, hydraulic cutting device, collecting table, hydraulic station, etc.
technical parameters - yx76-305-915
raw material carbon steel, galvanized steel, q235
material thickness 0.8-1.5mm
material width depend on specific profile
diameter of shaft 120mm
material of shaft 45# steel
material of rolls
gcr15 over quenching hrc 58-62°
main power 11kw*2
forming speed 15-20mmin
forming station 24-32 stations
cutting type hydraulic cutting
cutting blade
cr12 mov
