Metal Ridge Cap Roll Forming Machinery

Metal Ridge Cap Roll Forming Machinery Nowadays, Metal ridge cap roll forming machinery play a very important role in the steel structure building. Ridge Cap is used to cover the house ridge. It can perfect combination with roof tile and stop water run into the roof from house ridge. We can design different kinds of ridge cap machine accroding to client's requirement and help you build a beautiful with durable house. Decoiling the sheet→Sheet guiding→Roll forming→Measure length→Cutting the panel→Panels to product stand lower cost high efficiency reliable working  low energy consumption  Technical parameters: Raw Material A. Suitable Material: Colored Steel Plate, Galvanized Board, Aluminum Plate; B. Width of the raw material: 500mm;         C. Thickness: 0.3mm - 0.7mm; Main Body A. Roller station: 11 Stations;                       B. Diameter of shaft: ￠66mm, 45# steel; C. Roller material: 45# steel;                        D. Frame: 350 H steel; E. Operate: Manual and Automatic;             F. Working speed: 8-10 mmin; Power A. Motor power: 3 Kw,  Hydraulic power: 3 Kw; B. Voltage: 380V 50Hz 3Phases or Customization; Forming rollers Specification: 45# steel, CNC Lathes, heat treated  Feature: hard chrome
