Metal Roof Roll Forming Machine

We are offering metal roof roll forming machine.
Parts of equipment
1.un-coiler,
2.leveling device
3.main forming system
4.hydraulic cutting device
5.run-out table
6.electrical system (plc&hmi control system)
working flow :
decoiling�feeding�leveling-- forming--cutting--finished product
technological parameters:
export quality standard design:
1 main motor power:5.5kw
2 hydraulic station power:4kw
3 hydraulic oil pump:cb-e310
4 sprocket: p-25.4
5 roller station: 16
6 material of main shaft: high grad #45 steel, heat treatment
7 diameter of principal shaft: 80mm (add a key between axle and roller to fix)
8 material of roller: c45steel hard chrome plating
9 processing speed: 15mmin
10 thickness:0.2-1.0mm
11 installation dimension about(l*w*h):9.2*1.5*1.4m
12 total weight: about 6.6t
payment: tt, 30% in advance, 70% before shipment; delivery time: 40 days after receipt of the deposit;
packing: plastic film cover
installation: if necessary, engineer is available to service machinery overseas; but all the relevant cost and extra 50usdday for our engineer will be paid by the buyer. Warranty: 2 years since the machine leave seller's factory.
