Metal Seated Ball Valves VW-55Q

Metal Seated Ball Valves VW-55Q is 2-PC Flanged Ball Valve with Full Bore, Metal Seat and ISO 5211 Direct Mounting Pad. It has the Stainless steel, blowout proof stem. The valve is suitable for wide range of temperatures. The Design is with Fire Safe design, Low Torque release and Zero Leakage. Material of valve can be Carbon steel, Stainless steel and Special Alloy steel, etc. These valves are widely used in Refining, Power Generation, Oil / Gas and Pulp / Paper Industry, etc.
Specifications:
Pressure Rating: ANSI CL 150 / 300 and PN 10-40
Size: from DN 15 ~ DN 150
Seat: SS 316 + Solder Stellite#6 / HVOF
Ball: CF8M Solid Ball + Hard Chrome Plated / HVOF
Wave Spring (Inconel 750) design release torque with live-loaded function
Wall thickness complies with ASME B16.34
Safety/Quality Approvals: API 6D, CE, ISO, DNV approved factory
