Metallurgical Microscope

Our upright metallurgical microscopes are popular around the world for providing the best and most accurate results in minimal time. These high grade upright metallurgical microscopes are available with us with the following specifications & added advantages at consumer friendly price.

BINOCULAR OBSERVATION HEAD

• Siedentopf observation head inclined at 45°.
• Diopter adjustment ring on ocular tube (±5).
• Interpupillary distance from 53mm to 75mm.

Objectives (Infinity Corrected)

• M Long working distance plan 10X (WD 20.2mm)
•  M Long working distance plan 20X (WD 8.80mm)
•  M Long working distance plan 50X (WD 3.68mm)
•  M Long working distance plan 100X (S.L.) Dry(WD 0.40mm)

MECHANICAL STAGE

• Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
•  Quadruple nosepiece on ball bearing.
• Mechanical stage is 242mm X 200mm and moving range 30mmX30mm. Mechanical stage has low positioned co-axial controls on ball bearing guide ways.
•  Side port with phototube for micro photography.

ILLUMINATOR
Epi-Koehler’s illumination. Aperture iris diaphragm and field iris diaphragm 6V/30W halogen lamp. Adjustable brightness. Filter wheel fixed in light path with blue, green & yellow filters.

POLARIZING OUTFIT
Analyzer rotatable at 360°. Polarizer & Analyzer can be slide in/out of the optical path.

STANDARD ACCESSORIES
6V/30W halogen tungsten bulb, operating manual, dust cover, guarantee card and styrofoam molded pack.
