| ITEM MODEL | MIG200 | MIG250 | MIG315 | MIG250F | MIG315F | |||
| POWER SUPPLY(V) | AC220V+15% | AC415V+15% | AC415V+15% | AC415V+15% | AC415V+15% | |||
| INPUT CURRENT(A) | 29 | 14 | 14 | 14 | 14 | |||
| POWER CAPACITY(KVA) | 6.4 | 9.2 | 9.2 | 9.2 | 9.2 | |||
| CURRENT ADJUSTMENT SCOPE(A) | 50-200 | 50-250 | 50-250 | 50-250 | 50-250 | |||
| OUTPUT VOLTAGE (V) | 15-26 | 15-29 | 14-30 | 14-30 | 14-30 | |||
| RATED OUTPUT CURRENT(A) | 200 | 250 | 315 | 250 | 315 | |||
| RATED OUTPUT VOLTAGE (V) | 24 | 26.5 | 27 | 27 | 27 | |||
| DUTY CYCLE(%) | 60 | 60 | 60 | 60 | 60 | |||
| POWER FACTOR | 0.85 | 0.9 | 0.85 | 0.85 | 0.85 | |||
| EFFICIENCY(%) | 85 | 85 | 85 | 85 | 85 | |||
| WIRE FEEDER MODE | COMPACT | COMPACT | COMPACT | (SEPARATED) | (SEPARATED) | |||
| POST FLOW TIME(S) | 1 | 1 | 1 | 1 | 1 | |||
| SPOOL DIA(MM) | 270 | 270 | 270 | 270 | 270 | |||
| WIRE DIAMETER(MM) | 0.8/1.0 | 0.8/1.0 | 0.8/1.0/1.2 | 0.8/1.0/1.2 | 0.8/1.0/1.2 | |||
| APPLICABLE THICKNESS(MM) | >0.8 | >0.8 | >0.8 | >0.8 | >0.8 | |||
| INSULATER GRADE | F | F | F | F | F | |||
| HOUSING PROTECTION GRADE | IP21S | IP2IS | IP21S | IP21S | IP21S | |||
| WEIGHT(KG) | 25 | 26.5 | 29 | 23.3 | 25.3 | |||
| DIMENTIONS(MM)(L*W*H) | 500x263x430 | 500x273x440 | 500x230x420 | 500x230x420 | 500x230x420 | |||
