FeaturesAdvantage: To be used for the minimum sheet thickness of 0.6mm to 25mm High fusing capacity Suitable for solid wire as well as flux cored wire concentrated heat application Low deformation of welded parts., Equipment Consists Of Power Source, Wire Fe
Max Continuous Hand Welding Current at 60% Duty Cycle250A,400A,600A
Permissible Wire Dia (mm)0.8-1.2,0.8-1.6,0.8-2.4
Model NoBTIPL-MIG-250,BTIPL-MIG -400,BTIPL-MIG -600
KVA Rating at 60% Duty Cycle8.8 KVA,22.5 KVA,35 KVA
Supply Voltage380-440V
Welding Current Range50-250A,70-400A,100-600A
Insulation ClassH
Open Circuit Voltage18-38V,18-52V,18-56V
Max Continuous Hand Welding Current at 100% Duty Cycle180A,315A,480A
Type Of WindingCopper
Type of CoolingForced Air
KVA Rating at 100% Duty Cycle6.5 KVA,17 KVA,27 KVA
Cable Section4,8,16 mm2
FeaturesAdvantage: To be used for the minimum sheet thickness of 0.6mm to 25mm High fusing capacity Suitable for solid wire as well as flux cored wire concentrated heat application Low deformation of welded parts., Equipment Consists Of Power Source, Wire Fe
