Milk Packaging Machine, Brand Name : BEIYA

We offer bw-1000-2 type milk gable-top filling and packaging machines consist of two separate machines: carton forming machine and filling machine. The entire machine is made of 304 food-grade stainless steel, and the surface is special processed to be beautiful and durable in use.
1. Work flow:
1) carton forming machine: put the carton onto the mandrel (manually) -- bottom performing -- bottom heating -- bottom sealing
2) filling machine: put the carton onto the conveyor (manually) -- top performing -- filling -- top heating -- top sealing -- date printing -- finished product
the operation of the filling machine is automatically controlled by computer program, and others are controlled by electric apparatus. The whole progress is controlled by plc, needs 3 persons to operate.
2. Suitable for filling:
milk, yogurt, cream, beaten egg, soy milk, juice, tea drink, corn drink, pure water, sauce, cleaning solution, chemical product, sugar, grain, cornmeal, other dry powder, etc.
3. Technical parameter:
1. Capacity: 250--1000ml (can be filled by one machine)
2. Output: 800-1200 cartonshour
3. Packing material: cardboard carton aluminium foil carton
4. Filling temperature: cold filling: 2-5 degc hot filling 88-92 degc
5. Cap: without cap
6. Overall power: 22kw (three phases of electricity)
7. Size: (l*w*h): carton forming machine: 1.3m*0.9m*1.5m
filling machine: 2.0m*0.9m*2.6m
8. Compressed air pressure: 1.0-1.4 mpa, flow rate: 0.8-1.0m3min, without oil, water and dust
9. Cooling water: flow volume: ≥ 20l min temperature: normal temperature
10. Net weight: 1100kg, (carton forming machine: 300kg, filling machine: 800kg)
11. Installation requirement: any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle.
