Mini Gasoline Inverter Generator, Brand Name : YANGKE

We are offering mini gasoline inverter generator. ● digital inverter system:
high voltage multiphase ac power generated by the alternator and the ac power is then converted to dc. Finally the dc power is converted back to ac by the inverter unit. The inverter unit also smoothes and cleans the power.
● high quality power output:
a computer-controlled inverter system ensures stable high-quality output for electric tools, computer, tv set and other home appliances directly.
● high fuel efficiency:
manual / automatic (electronic governor) adjust the engine speed to produce only the power needed for the application in use for reduces fuel consumption, exhaust emissions and the noise.
● electronic circuit breaker:
automatically cuts off the electricity when the output current exceeds the designed capacity.
● 2.2hp reed valve gasoline engine:
compact size, high power, simple mechanism and easy starting.
● rare earth permanent-magnet alternator.
● patented design, lightweight delivers super portability-only 12kg.
*** specification ***
genset model yk1200i ( gs )
rated output power ( kw ) 1.0 ( cop )
max output power ( kw ) 1.1 ( s2 5min )
rated frequency ( hz ) 50
rated voltage ( v ) 230
rated current ( a ) 4.34
phase single
voltage fluctuation less than 3% ( none-full load )
dc output max 12v-5a
sound pressure level lpaeq,t 72.63 db(a) / 4m @ 75% load
alternator type rare earth permanent-magnet,
100% copper winding
engine model yk1e47f
engine type 2-stroke reed valve, forced air cooled
displacement ( cc ) 69
fuel tank capacity ( l ) 2.0
continuous running time ( hrs. ) 3.0 @ rated load
fuel type premix 50 cups of gasoline to one cup of 2 stroke oil
spark plug model f7rtc, bpr5es (ngk), w16epr-u (denso)
muffler catalytic converter ( euro ii )
starting system recoil start
packing size l*w*h ( mm ) 340×286×330
net / gross weight ( kg ) 12.5 / 13.6
qty / 20'gp / 40'hq ( sets ) 915 / 1,910.
