Mini Orb Corrugated Sheets Roll Forming Machine

We are offering corrugated sheets roll forming machine description:
all our machines are designed and manufactured according to customers’ requirements. This roll forming machine for mini orb corrugated sheets is used to produce corrugated roof panels. The machine consists of decoiler, guiding device, roll former, cutting device, hydraulic station, plc control system, etc. Beside these, we add a pre-form guillotine device for this machine to avoid waste of the material when changing to another coil in production.
technical parameters:
1.raw material: galvanized steel sheet, g550mpa
2.material thickness: 0.3-0.8mm
3.material width: 914mm
4.diameter of shaft: 75mm
5.material of shaft: 45# steel with heat treatment
6.material of rollers: 45# steel with quenching treatment hrc58~60 and chroming of 0.05mm thickness
7.main power: 7.5kw
8.power driving: chain and sprocket driving
9.forming speed: 8-12mmin
10.forming station: 20 stations
11.cutting type: hydraulic cutting
12.material of cutting blade: cr12 mov
