Mining Conveyor Belts Production Machine, Brand Name : XIANGJIE

This kind of Mining conveyor belts production machine can produce all types of belts with or without cleats, v-guides,for example flat nylon cord Conveyor belt , heavy duty belting, mining conveyor belts,rubber mat,rubber sheet etc..The width of the conveyer belt from 600mm to 2500mm.
So just tell us the standard of your product,we can offer you the proper machine and reasonable proce. So remember we Qingdao Xiangjie Rubber Machinery Co., LTD the 100% real machine manufacturer.
parameter adjustable
nylon cord conveyor belt machine Picture
Type
XLB-Q 1200×10000/36MN
Total Pressure (Ton)
3600
Platen size(mm)
1200×10000×80
Daylight (mm)
200-400
Plate unit area pressure(kg/cm2)
30
Piston diamterter (mm)
φ450
Piston stroke (mm)
400
Max. working hydraulic pressure(Mpa)
18.9
Max. working temperature (oC)
170
Max. steam pressure (Mpa)
1.0
Cylinder quantity(set/unit)
12
Motor power (kw)
33
Overall dimension (L×W×H)(mm)
6600×2350×4200
