Mono Block Carton Erection Machine

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

The machine is a mono block carton erection with pick and place top load filling CLD/carton bundles to be stacked on an adjustable magazine driven positively Cartons will be erected and presented....

View More Details

Send Enquiry

Company Information

Adhisakthi Projects Private Limited

Porur, Chennai, Tamil Nadu

View Number

Member Since 8 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

The machine is a mono block carton erection with pick and place top load filling
CLD/carton bundles to be stacked on an adjustable magazine driven positively
Cartons will be erected and presented to filling station along with flap locators
This is a single lane infeed model with single head pick and place mechanism
Product from end of line is arranged to the matrix size in the matrix table
Matrix layers are picked and placed inside the carton in sequence till top layer
The cycle repeats till the cld is filled with top layer and ejected on completion
Bottom and top taping are done by closing minor and major flaps automatically
Foor print : 2700 mm x 1650 mm / effective repeat cycles : Upto 20
ms base frame and safety covers with polycarbonate and limit switch interlock
PLC : Allen bradley make with HMI support with fault indication system
Festo/SMC pneumatics / air consumption 45 CFM @ 6 bar pr / power : 3 KW
Speed depends upon the matrix combination ( effective cycles x matrix size )
Infeed conveyor is with customer scope or supplied by us at additional cost.
Safety light curtains (beam sensors) are not a part of the scope which is optional
