Technical Specifications
| Basic Specification | |
| Engine model | D6114 ZG14B |
| Rated power/speed | 147kW/2200rpm |
| Dimension(LxWxH) | 8932×2625×3470mm |
| Operating weight(Standard) | 16000kg |
| Performance Specification | |
| Travelling speed ,forward | 5, 8, 11, 19, 23,38km/h |
| Travelling speed ,reverse | 5, 11, 23km/h |
| Tractive force(f=0.75) | 82 KN |
| Max. gradeability | 20% |
| Tire inflation pressure | 260 kPa |
| Working hydraulic pressure | 16MPa |
| Transmission pressure | 1.3, 1.8 MPa |
| Operating Specification | |
| Max. steering angle of front wheels | ±50o |
| Max. lean angle of front wheels | 17o |
| Max. oscillation angle of front axle | ±15o |
| Max. oscillation angle of balance box |  |
| Frame articulation angle | ±27o |
| Min. turning radius using articulation | 7.3m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90o |
| Blade cutting angle | 28o—70o |
| Circle reversing rotation | 360o |
| Moldboard width X height | 4270×610mm |
