Technical Specifications
| Basic specification | |
| Engine model | 6CTAA8.3 6CTA8.3 |
| Rated power/speed |  153kW/2200rpm 160kW/2200rpm |
| Dimension(LxWxH) | 8970×2625×3470mm |
| Operating weight(Standard) | 16500kg |
| Performance specification | |
| Travelling speed ,forward | 5, 8, 11, 19, 23 & 38 km/h |
| Travelling speed ,reverse | 5, 11 & 23 km/h |
| Tractive force(f=0.75) | 82KN |
| Max. gradeability | 20.00% |
| Tire inflation pressure | 260 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3 & 1.8MPa |
| Operating specification | |
| Max. steering angle of front wheels | ±50o |
| Max. lean angle of front wheels | ±17o |
| Max. oscillation angle of front axle | ±15o |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27o |
| Min. turning radius using articulation | 7.3m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90o |
| Blade cutting angle | 28o - 70o |
| Circle reversing rotation | 360o |
| Moldboard width X height | 4270×610mm |
