Contact SupplierWe are offering mud pressure gauge.
Better d and f type pressure gauges are popular and common tools in the drilling well, which is equivalent to oteco model 6 & 7camaraon f & d style.
type d:
dimensions: 7-58 “ diameter dial case
pressure range: 0-6,000 psi (1000 psi, 3000 psi, 5000 psi, 6000 psi)
standard end connection: 2” nptlpt female
interchangeable with: cameron type ‘d’, oteco model 7
sub connection: threaded lpt, flange 5k rj r-24, flange 10k rj bx-152,union 2” fig.1502 male
type f:
dimensions: 4-78 inch diameter dial case
pressure range: 0-20,000 psi
standard end connection: 2” nptlpt threaded female and 1” npt male .
Interchangeable with: cameron type ‘f’, oteco model 6
sub connection: threaded lpt, flange 5k rj r-2435, flange 10k15k20k rj bx-151152153154,union 2” fig.1502 male female
trim: salt water, sour gas, standard (mud, water, oil)
part no. Reference:
361111, 361121, 361211, 361231, 361221, 361411, 361431, 361421, 361511, 362411, 351541, 360056, 360057, 360000, 360002, 366431, 364701, 364581, 360059, 360058, 371211, 371311, 371411, 372201.
