Multi-Tube UN-Armoured Fiber Optic Cable

Company Information

Ask for more detail from the seller

Report incorrect details

Cable TypeMulti-tube Un-armoured cable
Brand NameLumiflex
Sheath optionSingle PE Sheath
Strength MemberFRP Rod
Fiber TypeSingle-mode or multimode
CompliancesIn Accordance with IEC,ITU and EIA standards
Note:Customised drum lengths available on request.
Sheath printing detailsLUMIFLEX Fiber Type, Fiber Count, Product Type, Month and year of Production, Special ID, Meter Mark
Lengths(tolerance ±5%)500Meter,1Km
PackingWooden drums /Plastic Drum
Operating Temperature-40℃ +70℃
FiberUp to 48,Gel -filled

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Colors

Fiber Standard Colour Code

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Feature

Application

Fiber transmission performance

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Optical Fiber (dB/km)	G652D (1310nm/1550nm/1625nm)	G657A1 (1310nm/1550nm/1625nm)	G657A2 (1310nm/1550nm/1625nm)
Max attenuation	0.4/0.3/0.3	0.4/0.3/0.3	0.4/0.3/0.3
Typical value	≤0.35/0.23/ 0.26	≤0.35/0.23/ 0.26	≤0.35/0.23/ 0.26

Technical Specification

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

able type	Maximum cores	Cable diameter(mm)	Tensile Strength		Crush Resistance		Mimimum bend radius		Cable Weight

			Short term	Long term	Short term (N/100mm)	Long term (N/100mm)	Dynamic	static
UNI-TUBE UN ARMORED	12	1	6.2	500	250	1500	500	60	30
UNI-TUBE UN ARMORED	24	2	7.5	500	250	1500	500	85	45
UNI-TUBE UN ARMORED	48	4	8.5	500	250	1500	500	85	45
