Product Details
Company Details

Multi-core Flexible Cables in different technical specifications are available to us. These cables have a contact construction, they are rugged, but flexible for industrial use and have high-temperature insulation. Our range of Multicore Flexible Cables can be availed in different types of insulation like Standard PVC, Heat resistant PVC up to105° C and Standard PVC Of FRLS, which finds varied application in the electrical industry. Available in standard width, these multicore flexible cables are offered at competitive prices.

Features:

Compact construction reduces weight per meter.
Rugged yet flexible for industrial use.
High-temperature insulation.

Technical SpecificationConductor:

High purity bright, electrolytic grade, plain annealed copper properly bunched having superb flexibility according to harmonized grades HO5V-K, HO7V-K and BS 6360 Class 5 available in various sizes. ‘Unilay’ conductor on the core will be provided on special order from 1 to 4 sq. mm.

Insulation :

Generally available with general purpose PVC insulation and PVC sheathing or as per customer

Standard Colours :

Grey & Black

Standard Packing:

100 mtr. Coils. Longer lengths supplied on order.

Applications and Standards

Type of Insulation	Type of Sheathing	Applicable Standards	Typical Applications
Standard PVC	Standard PVC, HRPVC	IS 694, BS 6500, IEC60227, DIN VDE-0281	Power cords for Appliances, Temporary Power supplies, 3 core flat cables are suitable for submersible pump applications.
Heat resistant PVC up to105° C	Standard PVC, HRPVC	IS 694, BS 6500, IEC60227, DIN VDE-0281	Hi-power Appliances, Ovens, Temporary Power Supply in higher temp, areas.
Standard PVC Of FRLS	FRLS (Flame Retardant Low Smoke)	IS 694, BS 6500, IEC60227, DIN VDE-0281, IEC 60754-1, IEC 60332-1, BS-4066-1, ASTMD2843, ASTMD-2863	Power cords for appliances used to fire-prone areas, flameproof equipment, machine tools used in critical locations and heat zones.

Physical and Electrical Properties

No. of Cores	Properties	05	0.75	1.0	1.5	2.5	4.0
CIRCULARLY	Conductor	16./0.2	24/02	32/0.2	30/025	50/0.25	56/0.3
LAID UP	Ins. thickness, (nom), mm	0.6	0.6	0.6	0.6	0.7	0.8
CORES	Single core OD (max.), MM	2.6	2.8	3	3.8	4	4.8
	Cond. resist, (max.), ohm/km	39	26	19.5	30.3	7.98	4.95
2 CORES	Sheath thickness, (nom), mm	0.9	0.9	0.9	0.9	1	1
RED, BLACK	Overall Dia. (max.), mm	7.2	7.8	8	8.6	10.5	12
	Current rating DC or single phase AC, amo.	6	9	14	18	24	32
	Voltage drop DC or phase AC, mV/ A/v	93	62	46	32	19	12
3 CORES	Sheath thickness, (nom),mm	0.9	0.9	0.9	0.9	1	1
RED, BLACK	Overall dia. (max.), mm	7.6	8.2	8.6	9.2	11	12.5
and GREEN	Current rating DC or single phase AC, amp.	6	9	14	18	24	32
	Voltage drop DC or single phase AC, mV/ A/m	102	62	46	32	19	12
4 CORES	Sheath thickness, (nom), mm	0.9	0.9	0.9	1	1	1
RED, YELLOW,	Overall dia.(max.), mm	8.2	8.8	9.4	10.5	12	14
BLUE and	Current rating DC or single phase AC, amp.	6	9	14	18	24	32
GREEN	Current rating three phase AC	6	9	14	18	20	25
	Voltage drop DC or single phase AC, mV/A/m	102	62	46	32	19	12
	Voltage drop, three phase AC	88	54	40	27	16	10
