Application:
The RNN Series Flute Laminator is specially designed for laminating top paperboard (≥350gsm) onto bottom paperboard or 2-ply corrugated board (A/B/C/E/F flutes). It is ideal for producing corrugated cardboard with high flatness and bonding accuracy.
Bottom sheet feeding is fully automatic
Top sheet feeding is manual, suitable for printed or coated sheets
Top Paperboard: ≥ 350 gsm
Bottom Sheet: 2-ply corrugated board (Flute Types: A, B, C, E, F)
Suitable for 3-ply board production
| Max. Sheet Size | 1000 x 1100 mm | 1300 x 1100 mm | 1450 x 1100 mm |
| Min. Sheet Size | 320 x 450 mm | 320 x 450 mm | 320 x 450 mm |
| Total Power | 7 kW | 7 kW | 7 kW |
| Laminating Speed | 0 – 90 m/min | 0 – 90 m/min | 0 – 90 m/min |
| Feeding Mode | Bottom – Automatic Top – Manual | Bottom – Automatic Top – Manual | Bottom – Automatic Top – Manual |
Smooth and Precise Feeding:
Automatic bottom sheet feeding for high efficiency and consistent alignment.
Manual Top Sheet Placement:
Ideal for printed or specialty paperboards where precise registration is needed.
Adjustable Speed Control:
Variable speed up to 90 meters/minute to match production requirements.
Durable Build & Compact Design:
Space-saving design with robust frame and easy operation.
High bonding precision and flat lamination quality
Compatible with various flute types
Easy to operate and maintain
Reliable for medium to high-volume production environments
