Non Woven Bag Machine

We are offering non woven bag machine.
item code: hnlc700
our organization is counted amongst the most distinguished importers and suppliers of a vast range of non woven bag machines. All our products are used for manufacturing non woven shopping bags, flat port bags, clothing bags, shoe bags, vest bags and other packaging bags. These electro mechanical integrative machines are fully automatic in design and are provided with touch screen operations for easy usage. Machines that we offer have photo electric tracing & computerized deviation rectifying functions. Our range comes with slotting, punching and metering devices. Moreover, clients can avail these in a variety of specifications as per their requirements.
features:
adopts pneumatic sealing system and can make bag have good sealing effect
spare parts are imported from aboard, such as omron reply and chint
high performance
low power consumption
the mainly ultrasonic sealing device from shanghai name brand company, this high quality device can make sure our machine have good bag making effect, and make sure our machine can bearing 24 hours working
multi-usage.
easy to operate
low rejection rate
adopts unique stainless steel guide folding design
adopts stainless steel cover
compact structure
model
hbl-b600
hbl-b700
hbl-b800
production speed
20 – 100 pcs/min
20 – 100 pcs/min
20 – 100 pcs/min
bag width
100 – 800 mm
100 – 800mm
100 – 800mm
bag length
200 – 480mm
200 – 580mm
200 – 680mm
non woven fabric specification
30 – 100 gsm
30 – 100 gsm
30 – 100 gsm
power supply
380v/220v
380v/220v
380v/220v
total power
11kw
13kw
15kw
overall size
6200 x 1650 x 1800mm
6200 x 1650 x 1800mm
6200 x 1850 x 2000mm
