Contact SupplierApplication:
wind speed & direction meter, gas meter, ultrasonic gas meter
specifications:
construction: rugged sealed
using method: dual use
center frequency: 200khzâ±7.5khz
working voltage: crest voltage less than 1000vpp
working temperature: -20 ~ +80 centigrade
pressure: less or equal to 3kg or 0.3mpa
angle: half-power angle: 8 â± 2 centigrade, sharp angle: 20 +- 4 centigrade
detectable range: 0.1 ~ 1.5m
blind area: 0.1m (can be customized into min 0.05m)
protection class: ip68
housing material: abs
corrosion resistance: can be used under the environment of weak acid or weak base
installation dimensions: 12mm.
