Oblique Arm Ce Screen Printer

We are offering tmp-70100-b oblique arm ce screen printer
technical parameters:
model no.
Tmp-70100
workbench area
800x1100mm
max printing area
700x1000mm
max screen size
1000x1300mm
min screen size
550x650mm
thickness of print (mm)
0-50mm
source power (kw)
2.3
rated voltage (vhz)
22050
printing speed (pcsh)
500-1200
machine size(mm)
1600x1350x1280mm
max table height
820
weight
480kg
application:
flat screen printer of this series is widely used in the packaging industry ( packaging, packaging, gift packaging and other card paper printing) trademark, calendar, oil painting, computer keyboards, paintings, iron-on transfers, credit cards, stickers, printing; also suitable for the printing of the electronics industry.
Features:
(1). Printing machine is driven by motor drive, which is belt drive, sensitive, balanced speed, speed adjustable.
(2). Oblique arm lifting motor, frequency control, the machine runs smoothly.
(3). Blade and back blade pressure regulating device, and can be adjusted to the thickness and size of printing.
(4). Vacuum adsorption fixed printing pieces.
(5). The printing plate has up and down, left and right, before and after tuning device, which makes it works accurate and convenient on board.
(6). Equipped with a safety device so that the oblique arm is stopped in an upper position having a reliable security.
(7). Electronic control unit centralized control by the microcomputer controller, the whole operation more simple, flexible, and easy maintenance.
