Electric Oil Pressing Machine, Brand Name : Goyum

Name: Oil Pressing Machine
Brand: GOYUM
Price: 6375000 INR
Availability: InStock

₹ 63.75 Lakh - ₹ 72.25 Lakh / piece

Company Information

4.5/5

(26)

View Number

Ask for more detail from the seller

Report incorrect details

ApplicationMulti Seed Oil Extraction
Warranty1 Year Against Manufacturing Defects
Brand NameGOYUM
CertificationISO 9001:2008 Certified, CE Certified, ISO 14001 : 2015 Certified
ConditionNew
Driven TypeElectric
Country of OriginIndia
Operating TypeSemi Automatic
SpecialitiesHigh Performance
Weight11,500 kgs
Model NumberGOYUM 600
Dimension (LxBxH)14’ x 5’6” x 16’6”
Kettle Motor3 Phase, 20 HP, 1440 RPM
Expeller Motor3 Phase, 100 HP, 1440 RPM
Crushing Capacity40 - 45 Ton in 24 Hours in Pre-Pressing, 30 - 35 Ton in 24 Hours in Single & Final Crushing
I Deal InNew Only

Oil Pressing Machine is used to extract oil from various types of edible as well as non-edible oil seeds & nuts.

Features:

Bodies and Base	Fabricated from Mild steel
Gearbox	Triple Reduction Gearbox with Helical Gears of Cast Steel and Pinions of Alloy Steel. Aligned with bodies on single fabricated base.
Chamber	Material: Cast Steel. Vertically fitted Feed End: - Size: Ø 9" x 36" Long, Discharge End: - Size: Ø 8" x 36" Long
Worm Assembly	Hard Face welded along with Discharge Ring and Sliding Ring
Main Worm Shaft	Can be withdrawn out without Disturbing the Gear Box. The Shaft is water cooled.
Crammer Shaft	For Extra Cramming of the Seed or Cake is fitted on the Feed Body and is driven by 2 H.P. Geared Motor.
Round Kettle (Cooker)	4 Stages with Steam Jackets of Ø 60” for efficient cooking of Seed. Pipe Fitting Contains Safety Valve, Steam Spray Pipe, Pressure Gauge, Steam Valves & Steam Traps. Exhaust Fan is also provided to extract excess steam or moisture from cooking chambers.
Cake Thickness	Can be Adjusted on Running Machine.
Oil & Oil Cake	Superior Quality
Maintenance	Minimum
Crushing Capacity	Differs with the density of oilseeds & nuts and quantity of oil in it.

Model	Capacity	Motor Power	Length	Breadth	Height
GOYUM 600	50 – 60 TPD* in Pre-pressing 30 – 35 TPD* in Single & Final Crushing	3 Phase 100 HP for Expeller	12 ft	7 ft	7 ft
Cooker/Kettle	--	3 Phase 20 HP for Kettle	7 ft	7 ft	12.6 ft

Payment Terms L/CT/T
Port of DispatchMumbai / Mundra
Packaging DetailsWrapped in polythene sheet & then Packed in Quality Wooden Box (For Export)
Delivery Time20 – 25 days, but confirmed delivery time will be provided at the time of confirmation of orde
