| Dew Point (Td) | ||
| Dew Point Sensor | : | HMC01 |
| Measuring Range | : | 25°C to + 65°C |
| Accuracy | : | Traceable to intern. standards, administrated by NIST, PTB, BEV... |
| Response Time t90 | : | 80 sec. -20°C Td —> -40°C Td (-4°F Td —> -40°F Td) 10 sec -40°C Td —> -20°C Td (-40°F Td —> -4°F Td) |
| Volume concentration | ||
| Measuring range | : | 20...200 000ppm |
| Accuracy at 20°C (68°F) and 1013mbar | : | 5ppm + 20% of reading |
| Outputs | ||
| Selectable and scalable | : | 0 - 10V -1mA< I,< 1mA |
| analogue output for Td, Tf, Wv | : | 4 - 20mA R < 500 Ohm |
| General | ||
| Supply Voltage | : | 21...28V DC |
| Current Consumption at 24V DC | : | voltage output: typ. 40mA / during autocalibration: 100mA |
| : | voltage output: typ. 80mA / during autocalibration: 100mA | |
| Pressure Range | : | 0...20bar (0...290psi) |
| Housing / protection class | : | Al Si Cu 3 / IP65 |
| Electrical connection | : | M12 connector |
| Sensor protection | : | stainless steel sintered filter |
| Working temperature range | : | probe: -40...70°C (-40...158°F) |
| electronic. -40...60°C (-40 140°F) | ||
| Storage temperature range | : | -40...60°C (-40...140°F) |
| Electromagnetic compatibility according to | : | EN 61326-1 EN61326-2-3 ICES-003 ClassB Industrial Environment FCC Part15 ClassB |
