Omicron DIGITAL MANMETER KELLER LEO2

Listing ID #3826795

Get Latest Price

Accuracy : ± 0.1% of F.S
Number of Digits : 5 Digit
Pressure Connection : 7/16”-20 UNF (adapter G 1/4” included)
Overpressure : 10 bar
Supply Type Manufacturer, Exporter, Supplier

Preferred Buyer From : All over the world

View More Details

Send Enquiry

Product Details

Accuracy : ± 0.1% of F.S
Accuracy RT (room temperature) * : < 0,1 %FS
Model : LEO2
Protection, CEI 529 : IP 65
Output : NIL
Supply : 3 V battery, type CR 2430
Weight : 125 g
Pressure Connection : 7/16”-20 UNF (adapter G 1/4” included)
Resolution : 1 mbar
Battery Life : 1’000 hours continuous operation
Storage- / Operating Temperature : -20…70 °C / 0…50 °C
Battery Life : 1000 hours
Diameter x Height x Depth : 59 x 95 x 32 mm
Total Error Band (0…50 °C) * : < 0,2 %FS
Pressure Range : -1…3 bar
Compensated Temperature Range : 0…50 °C
Temperature : 0 to 50°C
Range : -1 to 700 bar
Overpressure : 10 bar
Number of Digits : 5 Digit

LEO 2 is a compact, micro-processor (ìP) controlled, highly accurate and versatile pressure measuring instrument with digital indication. The piezoresistive pressure transducer as the heart of the instrument has gone through extensive pressure- and temperature tests. Its characteristics arestored in the instruments internal EEPROM. The ìP of the LEO 2 reads the characteristic values and calculates therefrom the pressure to an accuracy of < 0,1 %FS at room temperature.

The pressure is measured twice per second and displayed. The top display indicates the actual pressure, the bottom display shows the Max.- or Min.- pressure since the last RESET.
LEO 2 has two operating keys. The left key is to turn the instrument on, to select the functions and the pressure units. The right key executes the selected function or unit. The right key is also used to switch between the Max.- and Min.-value.
