Ophthalmic Surgical Operating Microscope (GTC-5)

The Ophthalmic Operating Surgical Microscope (GTC-5) is a vital part of our offered range of ophthalmic operating surgical microscopes. These are available in different customized specifications and forms as per requirements of our clients.
Our company is based out of Ambala, Haryana. We manufacture, supply, and export a wide range of medical equipment.

Technical specifications of Ophthalmic Operating Surgical Microscope (GTC-5) :

• 15x wide field eye pieces
• 3 step magnification (5x, 10x & 20x) or
• 5 step magnification (0. 4x, 0. 63x, 1x, 1. 6x & 2. 5) or continuous zoom (5x ~ 25x)
• Beam splitter with ‘c’ mount
• CCD digital camera
• Working distance - F = 250 mm for objective lens
• Inter-pupillary distance adjustment of 55 mm to 75 mm
• Manual or motorized focusing with foot control
• LCD monitor/screen which can be mounted on the microscope to display live surgery

Illumination section :

• Light source - 15Volt-150Watt/24Volt-250Watt with twin halogen reflector lamp
• Illumination control - Continuous adjustment
• Co-axial through-the-lens fiber optic light guide
• Field of illumination - 70 mm
• Filter - Cobalt blue, red-free, and heat absorbing

Stand section :

• Mobile floor stand on four castor wheel
• Arm length - 300 to 560 mm
• Rotation of arm - 320 degrees with lock

Optional accessories available with Ophthalmic Operating Surgical Microscope (GTC-5) :

• Monocular assistoscope
• Objective lens 250 mm 300 mm & 400 mm
