Optical Ampoule Vial Inspection Machine

The filled ampoules are loaded in to the infeed chute from where they are transferred in batches by an index wheel onto a linear transfer rack. The rack transfers the ampoules onto the inspection station, where spinners spin the ampoules at a predetermined RPM so that a vortex is formed. Illumination from behind the ampoules assists in light refraction of particles/fibers . An operator views six ampoules through a magnifying glass

Salient features of Optical Ampoule Vial Inspection Machine

• All contact parts in stainless steel.and approved engineering plastics.
• Spinning of ampoule/vial.Magnifyed view with back lighting
• Clear view of six ampoule/vial.
• Modular and compact ejection system.
• Rotation of spinners can be adjusted to give desired vortex on liquid
• Easy access for cleaning and maintenance.
• Large inspection to transport time ratio.
• Facility of repeat cycle.
• PLC assisted failsafe rejection.
• Counters for good and reject products.

Technical Specifications of Optical Ampoule Vial Inspection Machine

• Output(Ampoules) : 60-72/minute
• Output(Vials) 48-56/minute
• Electrical Ratings : 3ph. 415V. 50 cps. (4 wire)
• 0-75 HP main motor
• 0-25 HP spinner motor
• Net Weight : Approx. -450 Kg.
• Handling Range (in mm) :
• Diameter Min. 9 Max. 15 mm
• Height Min. 60 Max. 116 mm
