OPTICAL VISUAL VIALS INSPECTION MACHINE

MODEL: AHIM 3 & AHIM 4

SALIENT FEATURES:

• All contact parts in stainless steel and approved engineering plastics..

• Spinning of vial Magnified view with back lighting

• Clear view of four vials.

• Modular and compact ejection system.

• Rotation of spinners can be adjusted to give desired vortex on liquid

• Easy access for cleaning and maintenance.

• Large inspection to transport time ratio..

• Facility of repeat cycle.

• LED as well buzzer assisted safe rejection.

• Counters for good and reject products.

OPERATION:

• The filled vials are loaded in to the infeed turntable from where they are transferred in batches by an index wheel onto a linear transfer rack.

• The rack transfers the vials onto the inspection station, where spinners spin the vials at a predetermined RPM so that a vortex is formed. Illumination from behind the vials assists in light refraction of particles/fibers .

• An operator views four vials through a magnifying glass.

• The vials are rejected by pressing rejection switches ergonomically located for operator convenience. A numbered light positioned just above the magnifying lens within the operator's field of vision lights up indicating a rejection In case a recheck is desired before checking the next lot, a facility for repeat cycle is provided.

• The vials batch is then transferred onto the rejection station where the vials rejected at the inspection station are automatically ejected out. A numbered light lights up above the lens indicating a positive rejection taking place. In addition a rejection LED as well buzzer assists in tracking the actual rejects of objects.

• The accepted vials are transferred onto the collection station where there are collected in a tray.

• MACHINE IS SUPPORTED WITH DOUBLE BACKGROUND OPTION TO DETECT BLACK AS WELL WHITE PARTICALS.

Electrical rating	Main machine : 0.75 hp, 1440 rpm Spinning assembly : 0.25 hp, 1440 rpm
Power characteristic	220 volts, 1 phase,
Finish/painted	S. S. Finish
Overall dimensions	1600 mm (l) x 1100 mm (w) x 1600 mm (h)
Net weight	500 kgs.
Output(ampoules)	60-72/minute (depend on operator’s skill)
Output(vials)	48-56/minute (depend on operator’s skill)
Loading and unloading	As per your requirements
Input specifications:	2ml to 10ml vials can run in four head machine (four vials come in to inspection zone) and if to run 2ml to 30ml vials machine fitted with three heads (three vials come in to inspection zone)
