ORING IGPS-1082GP Series Industrial 10-port Unmanaged Gigabit PoE Ethernet Switch

Support 8 ports IEEE 802.3at compliant PoE and total power budget is 120W with maximum 30W per port of 24V mode Total power budget is 180Watts with maximum 30Watts per port of IGPS-1082GP model

• •
    • Support up to 9.6K Bytes Jumbo Frame

    • Support up to 4Mbit Packet buffer

    • Support auto-negotiation and auto-MDI/MDI-X

    • Support store and forward transmission

    • Support flow control

    • Provided relay output for power failed warning system

    • Provide DIP-switch to setting SFP speed

    • Rigid IP-30 housing design

    • DIN-Rail and wall mounting enabled

Industrial 10-port unmanaged Gigabit PoE Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. and

Overview

IGPS-1082GP series is full Gigabit unmanaged PoE Ethernet switches with 8x10/100/1000Base-T(X) P.S.E. ports and 2x100/1000Base-X SFP ports. IGPS-1082GP series also support Power over Ethernet, a system to transmit electrical power up to 30 watts, along with data, to remote devices over standard twisted-pair cable in an Ethernet network. Each IGPS-1082GP series switch has 8x10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports.  P.S.E. is a device (switch or hub for instance) that will provide power in a PoE connection.  And support wide operating temperature from -40 oC to 75 oC.  Therefore, the switch is one of the most reliable choices for rolling stock and highly-unmanaged PoE Ethernet application.

Features

 2x100/1000Base-X, SFP socket
