Overview

IGPS-1411GTP-24V is an unmanaged PoE Ethernet switch with P.S.E. function. IGPS-1411GTP-24V supports Power over Ethernet, a system to transmit electrical power, along with data, to remote devices over standard twisted-pair cable in an Ethernet network. IGPS-1411GTP-24V has 4x10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports, 1 additional Gigabit port, and 1x100/1000Base-X SFP port. The SFP port optical network speed can be set by changing the settings of the DIP-Switch below. IGPS-1411GTP-24V supports wide range 12~57VDC power inputs and generates 50VDC P.S.E. power output per port. P.S.E. is a device (switch or hub for instance) that will provide power in a PoE setup. The wide operating temperature range from -40°C to 75°C can satisfy most of operating environment. Therefore, the switch is one of the most reliable choices for PoE Ethernet application.

 Features

• • IGPS-1411GTP-24V provide 4x10/100/1000Base-T(X) PoE (P.S.E.) ports

  • Support P.S.E. based on IEEE 802.3at standard up to 30 Watts per port

  • Supports Jumbo frame up to 10KBytes

  • SFP port support 100Base-FX and 1000Base-X speed

  • Support auto-negotiation and auto-MDI/MDI-X

  • Support store and forward transmission

  • Support dual wide range 12~57VDC power inputs for power redundancy

  • Supports flow control

  • Rigid IP-30 housing design

  • DIN-Rail and wall mounting enabled
