Outdoor Power Inverter ONS-A1500N With Charger Solar System

ONS-A1500N
Inverter is a way to convert DC to AC power conversion device.12VDC or 24VDC input,220VAC/50HZ or 115VAC/60HZ
Modified Sine Wave Output.1000 ~ 3500W series ideal for industrial and commercial electricity inverter to provide AC output as the same household electricity socket. Can supply a range of industrial equipment, electrical power,
for commercial lighting and refrigeration equipment. Inverter has a wide range of uses, but also can be used for outdoor recreation
and electronic tools for power supply. As technology advances, users need to move electronic equipment used in ancreasing number
of inverters can be ready for these devices to provide sufficient AC power, to provide users with aonvenient mobile power.
A. scope of application:
1. Travel Equipment Series: Military vehicle, police cars, ambulances, ships, trucks, cars and so on.
2. Office equipment series: computers, printers, monitors, copiers, scanners, digital cameras, digita l cameras and so on.
3. Efield series: TV, DVD, game consoles, power amplifiers, audio equipment, monitoring equipment, servers, satellite communications equipment.
B. the main function and protection:
1. Overtemperature protection: If the inverter internal temperature or ambient temperature is too high , inverter will automatically stop
the output temperature protection to ensure safety of electrical eq uipment.
2. Battery low voltage protection: When the battery or power supply voltage is too low, the inverter will automatically shutdown protection to stop
exporting in order to protect the battery or power supp ly is not impaired Harm. When the voltage is back to normal, the inverter automatically back to work.
3. A lowbattery warning: When the battery voltage is below the normal range, the inverter will issue a warning sound to remind the user battery needs to recharge.
Time Users should stop the op e ration of electronic equipment as soon as possible to charge the battery.
4. Battery overvoltage protection: When the DC input voltage range above the normal level when the in verter will automatically shut down to stop the output,
note the voltage is too high, may be May damag e the machine.
5. Overload protection: When connected to the load exceeds the inverter rated power watts (W), the inverter will automatically shut down to stop the output.
After the removal of overload, auto-return Reha bilitation work.
6. Shortcircuit protection: When connected to the load severe shortcircuit fault, inverter will auto matically shut down to stop the output.
After the removal of short-circuit to automatically return to normal work.
7. Earth leakage protection: inverter in accordance with national security and leakage protection stan dards. When the earthing terminal there is leakage occurs,
the leakage protection circuit to quickly t urn off inverter To prevent electric shock to the people. In case of electricity leakage problem, you must immediately
close the inverter, unplug the AC there is leakage of suspicious loads, and then reopen the inverter switch button.
Specifications
Rated power
1500W
Output voltage
AC110V/AC220V 60Hz/50Hz
Input voltage
DC12V/24V(Optional)
Output waveform
Modified sine wave
USB output
5V/0.5A
Protection Function
Over voltage shutdown/Low voltage shutdown/Overload protection
Sheathing material
Aluminium Alloys
Size:L×W×H
250×180×55 mm
N.W
2.3 Kg
