Paddle Flow Switches

MOQ1 Piece(s)
Corrugated tube life500,000 times
OutputMechanical switch NO+NC (250VAC,3A)
Repeatability±2.5% of full scale
Protection classIP54
Supply TypeManufacturer
Preferred Buyer Location All over the world

Product Details

Avg pressure loss0.08bar（Max. flow）
Repeatability±2.5% of full scale
Connection typeTerminal connection
OutputMechanical switch NO+NC (250VAC,3A)
Protection classIP54
Corrugated tube life500,000 times
Withstand voltage:16 bar（40bar optional）

We are offering plug in paddle flow switches.
it is plug-in installation, mechanical flow switches. The built-in micro trigger switch.
characteristics
1.minimal pressure loss, good repeatability, dirt-resistance,
2. Through the knob to achieve accurate switch setting
3.hermetic separation of mechanical.
4.at the time of delivery is accompanied by 5 baffle plates, on the large diameter pipeline with low velocity or not full,the user can flexibly use according to the actual situation.
5.the same kind of switch can be used for various pipeline.
