Paper Rolls Slitting Machine, Brand Name : QUNTUO

Model
smg1400／1700／1900
specifications
1400,1700,1900
trade mark
quntuo
packing
wood
use
packaging paper
type
paper cutting machine
technological process
finishing processing machinery
output
50
product details
1. Advantages of reel slitting machine:
model:smg1400／1700／1900
the slitting machine adopts ac servo motor to drive the paper. It is fast and stable;
germany precision cutting knife, cutting accuracy is high ± 0.5mm;
three component strip cutters are available for trimming and slitting
light touch computer interface operation, easy to operate;
it is more equipped with tension control system than the same type of slitting machine. The paper feed is smooth, and the paper is upright;
compared with the same type of slitting machine, reducer, transmission machinery, service life of at least ten years.
The lifting platform adopts chain drive (peer first), which is more durable and more convenient to maintain than the traditional oil cylinder steel wire rope.
The highest cutting speed is 400 pieces per minute
2, slitting machine parameters:
reel slitting machine, specification, model qt-1400／qt-1700／qt-1900
paper cut type, top knife back cut, lower tool fixed
applicable paper range 55-550g
cutting accuracy ±0.5mm
maximum cutting speed 400cuts／min
maximum cut-off meter speed 320m／min
cutting length range of web slitting machine 450〜1450mm
