Explosion protection ATEX II 1/2G Ex ia IIC T4/T6 Ga/Gb ATEX II 1D Ex ia IIIC T107 °C IP6X Da ATEX II 1G Ex ia IIC T4/T6 Ga
Baud rate 38,4 kbaud (COM2)
Standard error of measurement (BFSL) ± 0.04 % FSR ± 0.1 % FSR Including non-linearity, hysteresis and non-repeatability according BFSL
Max. measuring span 40 bar
Long term stability ≤ 0.1 % FSR/a , measuring range > 1 bar ≤ 1 mbar , measuring range ≤ 1 bar
Min. measuring span 0.1 bar
SIO-mode No
Cycle time ≥ 2.3 ms
Max. measuring error ± 0.1 % FSR ± 0.25 % FSR Including zero-point and span error, nonlinearity (by terminal base line), hysteresis and non-repeatability (EN 61298-2) For turndown, multiply this value by the applied turndown ratio
Measuring range -1 … 40 bar
IO-Link port type Class A
Pressure type Absolute Relative (gauged)
Temperature coefficient ≤ 0.03 % FSR/10 K , measuring span ≤ 0.03 % FSR/10 K , zero point
Process data length 24 bit
Max. turndown ratio 05:01:00 AM
Process data (cyclic)Â Process pressure
