Contact Supplier1.Automaticlly board transferred, cleaned plates can be set to send on former direction;
2.Two static rod, destaticize and clean in double sides, the pressure of sticky roller is adjustable;
3.Entry stack and Exit stack;
4.Variety of working mode, fit in both stand alone and online;
5.Flexible board or rigid board choosen available;
6.Dust sticky paper is in drawer type, convenient cleaning, cutting and changed, surface cleaned more thoroughly.
Technical data
工作尺寸Production size | 150-650mm |
滚筒宽度 Roller length | 770mm |
粘尘轮宽度Dust sticky roll length | 650mm |
静电棒static bar | 2支 Two |
粘尘棒 Dust sticking bar | 2卷(上下各一卷),可从侧面抽出 |
厚度 Thickness | 0.2-4mm |
压力 Air pressure | 5.0kgf/cm² |
传送速度Transmission speed | 0-10m/min |
适用Apply | PCB/金属(铭板)/各种软片/钢板/LCD 薄膜得便法除尘PCB/Metal plate/ Steel plate/LCD Thin film |
电源Power | 1ph AC220V |
重量Net Weight | 100kg |
