PEEK Extrusion Sheet

PEEK extrusion sheet PEEK (Polyetheretherketone) offers good wear resistance and can be used continuously to 250 ℃ in hot water or steam without permanent loss of physical properties. It is very chemically resistant with inherently low flammability and smoke emission.   The PEEK sheet is manufacturerd with continuous extrusion process.It has better uniformity,which is widely used for CNC process. Thickness average is better than molded processing.We sicceed om extruding thick sheet with the large cross section size.We also have molds in stock for the needs of different industries.   Photo     Specification   NO Dimension(mm) Weight(g) 1 0.5*700*1000 480 2 1*700*1000 950 3 2*700*1000 1900 4 3*700*1000 2800 5 4*650*1000 3400 6 5*650*1000 4300 7 67*31*1000 2700 8 80*15*1000 1560 9 100*25*1000 3100 10 120*38*1000 5500 11 195*33*1000 8365 12 175*162*1000 36855 13 395*12.5*1000 6419 14 422*15*1000 8229 15 422*66*1000 36207 16 Insulation block(with U type)280*45*1000 15000 17 600*6*1000 4680 18 600*8*1000 6240 19 600*9*1000 7020 20 600*15*1000 11700 21 600*20*1000 15600 22 600*25*1000 19500 23 600*30*1000 23400 24 600*35*1000 27300 25 600*40*1000 31200 26 600*45*1000 35100 27 600*50*1000 39000 28 600*60*1000 46800 29 800*20*1000 20800 30 800*30*1000 31200     Main Properties.
