Picosecond Diode Laser For Absorption Spectroscopy

Product Description  Picosecond Diode Laser  Picosecond diode lasers feature with narrow pulse duration, high repetition frequency and easy operation. They are widely used in fluorescence excitation, time resolve spectrum, high sensitive absorption spectroscopy, etc.  PICOSECOND RED DIODE LASER AT 640nm Wavelength (nm) 640±3 Operating mode Pulsed Output power 50μW-3.5mW Pulse width (ps) 100-1000 Repetition frequency (MHz) 1~80 Beam diameter at the aperture (1/e2, mm) ~1.3 Beam height from base plate (mm) ~1.0 Beam divergence, full angle (mrad)  26.5 Driver (12VDC 4.2A) PSU-III-PS Warranty 1 year   PICOSECOND RED DIODE LASER AT 785nm Wavelength (nm) 785±5 Operating mode Pulsed Output power (mW) 70μW-4.2mW Pulse width (ps) 100-1000 Repetition frequency (MHz) 1~80 Beam diameter at the aperture (1/e2, mm)  ~2.0 Beam divergence, full angle (mrad) ~1.5 Beam height from base plate (mm) 26.5 Driver (12VDC 4.2A) PSU-III-PS Warranty 1 year   PICOSECOND RED DIODE LASER AT 808nm Wavelength (nm) 808±5 PulsedOperating mode Pulse width (ps) Output power (mW) 90μW-6.0mW Pulse width (ps) 100-1000 Repetition frequency (MHz) 1~80 Beam diameter at the aperture (1/e2, mm) ~2.5 Beam divergence, full angle (mrad)  ~1.5 Beam height from base plate (mm) 26.5 Driver (12VDC 4.2A) PSU-III-PS Warranty 1 year Dimensions    Picosecond-Laser-Head Picosecond-Laser-Controller Power Supply
