Piling Rig RG19 T BAUER

We are offering technical details of the RG 19 T
year of manufacturing: 2013
hours of operation: approx. 2300
the machine is full checked full by the rtg and caterpillar!
all documents are present.
Base carrier: bs 65 rs
diesel-engine : cat c18 Tier 4
rated output - (563 kw)
max.mast height(leader extended, min.work radius)22,80 m -length of mast(leader retracted)- 20,20 m-
Max.length of piles(with vibrator, min.work radius) -19,80 m-
Working radius(min.) - 4,30 m.-14,1 ft.
Swing radius 3,50 m-11,5 ft.
Removable counterweight
transport securing lugs on crawler unit,
equipped with: winch 5,5 t,
central lubrication system,
b-tronic rg-modul + vdw modul super for drill start
with the vibrator: mr 145 v !!! (used, jahr -2012)
max. Centrifugal force:1450 kn.
Max.speed: 2200 1 min
static moment: 28.4 kgm
OPTIONAL !!
used rotary head bauer mb75 (torque 75 knm)
technical provision for (pre-equipped) for:
mb 20, mb 50 for drill-work piling press
we can arrange delivery to any given place.
the machine is rented now but if you are interested in seeing it working that can be arranged.
