Plasma Cutter

We offer Plasma Cutter.
×the unit adopts casting frame work, y axis adopts gear wheel and rack moving ,x z axis adopts precise ball bearing rail moving, imported high precision slide ways, thus the working speed and precision is guaranteed well.
×adopting electrical current adjustable plasma power supply to regulate the current according to the thickness of different materials, thus coarse of the material is avoided.
×professional non-touching plasma head, it can cut kinds of metallic materials with 1-30mm thickness.
×more advanced dsp digit-control system, handle operation and large liquid crystal display brings out more convenient operation, simpler maintenance and much more human nature on the machine.
×unique intelligent calculation fully develops the potential of the spindle motor and leads to high speed processing, the synchronization of curves and straight lines, smoother curves.
×unique and dynamic renewal ability of the system make the performance more efficient.
×large internal memory capacity is able to store more then 30 processing files simultaneously and open and process any of them
×connection with tie computer via usb interface enables data to be transmitted in a second, supports hot plug and play, in the system(window98/2000/xp).
×more compatible with series of cad/cam software like type 3, artcam, castmate, proe,ug,artcut, etc.
×it is mainly used to cut kinds of metallic materials, such as armor plate, aluminium, iron and cuprum, and so on.
machine parameters of functions:
working area:2900×1320mm
travel of engraving:2500×1300×90mm
maximum speed:10000mm/min
manner of receiving data :usb / hard disk
capacity of memory:128m
format of instructions:g code,hpgl
power supply:ac220/50hz
electric power:600w
driving system:step
weight:380kg
plasma parameters of functions:
input power:3~380v±20%/50hz
rated input current:60a
rated input current:12kva
rated cutting power:60a
rated cutting voltage:90v
rated adj range:15--60a
rated duty cycle:60% / 40degree
