Plastic Friction Testing Machine, Brand Name : Yihua

We are offering plastic friction testing machine,
mmu-10g screen display project plastic and alloy high temperature end-face friction and wear testing.
application:
mmu-10g screen display high temperature end face friction and wear testing machine is used for testing the friction capabilities of project plastics, powder metallurgy and alloy bearing under the sliding friction. It operates under the conditions of room temperature or high temperature and changing all the parameters such as lubricant state (non-oil lubrication or oil soaking lubrication), load, speed, friction spouse material, roughness of friction subsurface and hardness, etc. It also can be used to test the temperature and frictional coefficient of materials.
main technical parameters
model mmu-10g
range of testing force 1~10kn
accuracy of testing force display value ±1%
accuracy of automatically maintain display value of testing force ±1%fs
range of friction measuring 10~500n
accuracy of display friction ±2%
range of spindle speed 5~2000rmin
accuracy of spindle speed ±10rmin
temperature rang room temperature ~600°c
rubbing pair for test according to customers’ requirements
cellar stroke >45mm
power of main motor 4kw
range of display time 1s~9999min
range of display revolution 9999999s
dimension about 1200×870×1700min
weight 850kg
self-protection (in the following conditions, this device start self-protection system automatically) exceed operation
exceed preset time
exceed preset revolution
exceed max. friction.
