Platelet Agitator

Features of Platelet Agitator :

• Digital temperature recorder
• Controller unit coupled with a unique air flow system to maintain the chamber uniformly at the AABB recommended temperature of 22 +/- 0.1ºC.
• Digital sensor placed inside the solution-filled bottle.
• Pause switch provided to arrest agitator motion for 10 seconds, for easy placement and removal of bags.
• Toughened glass door for safety and better visibility of platelet bags.
• Magnetic gaskets for doors ensure no air is lost in a ‘door closed’ condition.
• The internal fan switches off when the door is opened to avoid the loss of cold air.
• Eyelevel positioning of TRCU for better visibility.
• Automatic illumination when the door is opened allows for better visibility.
• The stabilizer protects the incubator from input voltage fluctuations and ensures that the equipment has a long life-cycle

General Features of Platelet Agitator :

• Temperature range:  22°C with micro controller based temperature controller.
• Includes digital temperature display of set value and process value.
• Cabinet Construction of platelet incubator.
• The cabinet of Meditech platelet incubator agitator is insulated with high density CFC free Poly Urethane Foam of 120 mm thick insulation.
• Interior chamber of platelet agitator is finished resistant stainless Steel (304, 0.8 mm thick).
• The exterior of platelet agitator is Sky Blue Pure Polyster powder coated (1.0 mm thick) Mild Steel and the door has a magnetic gasket with a keyed lock.

Refrigeration system of platelet agitator :

• Platelet incubator Agitator uses Heavy-duty, air-cooled refrigeration system.
• Forced air circulation maintains chamber uniformity of +/-1°C.
• Provides quick recovery after door openings of platelet agitator.
• Non-CFC refrigerant is used in platelet agitator.
• Automatic condensate evaporator is implemented.
• Internal evaporator fan shut off during door openings of platelet agitator.
• Defrost cycle is used to maintain constant temperature.

Temp Controller of platelet Agitator :

• Micro processor based temperature control with accuracy of ±0.1ºC.
• Smart controller saves the current consumption by more than 30%.
• Quick recovery of temperature after opening of Door of platelet agitator.
•  Audio Visual Alarm
• Audio Visual Alarm is activated when the door is opened in platelet agitator.
• Audio Visual Alarm is activated when temperature deviates from preset temperature.
• Chart Recorder used in platelet incubator agitator.
• Controller

Led Indication :

• Line In
• Power
• Comp On
• Heater On
• Battery On
• Battery Low
• Temp High
• Temp Low
• Power Fail
• Sensor Fail
• Chart Change
• System On
• Scrolling LIVE Data logger on LED screen
• Temperature
• Incoming Voltage
• Ambient Temperature
• Time in hours of revolution chart
• Current Date
• Current Time
• Battery Voltage User
• User Friendly Settings
• Date
• Time
• High Temp Alarm
• Low Temp Alarm
• Hysterisis
• Compressor Delay
• Platelet agitator has inbuilt 7 days circular Chart recorder.
• Platelet Agitator T-Series -Touch Screen Series with PLC

Special Features :

• large 7 inch touch screen with display of set and process value.
• Precise control of temperature by using micro controller based temperature controller.
• Multiple language can be displayed on screen including English.
• Integrated digital temperature cum controller with inbuilt 7 days circular chart recorder.
• Battery back up of 24 hours of touch screen to ensure display & recording of temperature during power failures.
• Integrated data management system with storage efficiency of temperature records up to 1000 readings & facility to transfer data through pen drive to PC.
• large 7” touch display with facility to see current and last 24 hours temperature recording, High & Low alarm points with date & time recording and power resumption.
• Audiovisual alarm if the temperature deviates from the set temperature.
• Display of set value and process value.
• Castor wheels for ease of mobility.

Printing Option : Supports following Dot matrix serial printers :-

• EPSON,SAMSUNG,TVS
• S-Series – Touch Screen Series with PLC and SCADA

Other Detaills :

• All Special Features of T-series are included Along with
• SCADA system connected through a remote alarm system, to a central monitoring systems.
• Model Number will remain same for M-Series, W-Series, T-Series and S-Series.
• Kindly mention series while ordering
• Optional Accessories Stand by Refrigeration system
• Ready to use stand by refrigeration system in case of regular system fails. This includes Compressor, Evaporator, condensers and other accessories
