Contact SupplierFEATURES
Low pressure drop;
Pleated design and more filter area for in creased contaminant removed;
Long filter runs, longer life used;
The polyester media may be cleaned and cartridge maybe re-used;
Thermally-bonded construction with media, end caps and inner code heat sealed together
APPLICATIONS
Pre-filter of drinking water system
Swimming pool water system
Pre-filter of R.O system and general commercial water system
Pre-filter of DI & RO water filtration system for industry.
Filtration of medium & low viscosity fluids of chemical.
Filtration of water for manufacturing processes and recycled water.
OPERATION CONDITIONS
Maximum operating pressure 80PSI
Maximum operating Temperature 40℃~80℃
CONSTRUCTIONS AND MATERIALS
Media: Non-Woven Polyester Fabric
Non-Woven Polypropylene Fabric
End Caps: Vinyl Plastisol
Inner Core: Polypropylene
Outer sheath: Polypropylene
RETENTION RATINGS (μ m)
Nominal 1, 5, 10, 20, 30, 50, 75 micron
SPECIFICATIONS
Inner diameter: 28mm
Outer diameter: 68mm~112mm
Length:127mm~762mm
