BITUMEN PUMP
2" x 2" Size Positive displacement Gear Pump with output 350 liters/min. (Max.)
DRIVING UNIT
Kirlosker/HTC Vertical air Cooled diesel engine.
OPERATOR PLATFORM
Techometer : Slow Speed 0.5 Metre /min.
AIR COMPRESSOR
Make - ELGI/INDOAIR 2 CYL, 3H. P. Working
Pressure 9kg/cm2 13.25 M3, Capacity 360 L.P.M. 550 R.P.M.
BITUMEN SPRAYING PRESSURE
0 To 6 Kg/cm2.
TEMPERATURE GAUGE
0-250c at Front of Tank
| MODEL | ATM - 5000 | ATM - 6000 | ATM - 7000 |
|---|---|---|---|
| Length | 2500mm. | 3100mm. | 3300mm. |
| Width | 1800mm. | 1900mm. | 1900mm. |
| Height | 1500mm. | 1550mm. | 1650mm. |
| Capacity | 4000Ltrs. | 6000Ltrs. | 7000Ltrs. |
| Man Hole | 600mm. | 600mm. | 600mm. |
| Insulation | 50mm. | 50mm. | 50mm. |
| Fuel Consumption of Burner | 20 Ltrs | 20 Ltrs. | 20 Ltrs. |
| Burner | Compressed air type | Compressed air type | Compressed air type |
| Mounting | Ashok Leyland or Tata | Ashok Leyland or Tata | Ashok Leyland or Tata |
| Wheel Base | 176"/166" | 176"/166" | 176"/166" |
| Bitumen Tank Shape | Ovel Shape | Ovel Shape | Ovel Shape |
