Contact SupplierTechnical specification:-
Specification | Metric | Imperial |
Weight | 9.8 kg | 21.6 lb |
Length | 565 mm | 22.2" |
Impact Rate | 2580bpm | |
Penetration Rate | 220 mm/min | 8.6 in/min |
Piston Dia | 45 mm | 1.77" |
Piston Stroke | 41 mm | 1.61" |
Air Inlet | 19 mm | 3/4” |
Air Pressure | 6 bar | 87 psi |
Air Consumption | 24 l/s | 51 cfm |
Shank Size | 22 x 108 mm | 7/8" x 4¼" |
Shank Size (optional) | 19 x 108 mm | 3/4" x 4¼" |
| Model | Nt.Weight | Length | Piston Dia | Stroke | Air Requirement | Frequency | Drilling | Hose size |
|---|---|---|---|---|---|---|---|---|
| kg ( lb) | mm (in) | mm (in)s | mm (in) | At 6 bar I/S ( foot 3/Min) | b.p.m | Mm/min (feet/Min) | mm (in) | |
| ACE 10 RD | 9.8 (21.6) | 565 (22.5”) | 45 (1.77) | 41 (1.61) | 24 (51) | 2580 | 425 (1.40) | 12.7 (1/2) |
