Buying guide
 & working material:aluminium profile, sheet material, window and curtain wall profile
 & need perfect crimping process to get more ordersÂÂ
 & profile height 160mm need process
technical parameter
name parameter
profile processing height 160mm
input voltage 220v 50hz
inner position corner moving range 130mm
cutter feeding range 0-20mm
corner head adjustment range 70mm
air pressure 0.5-0.8mpa
general pressure of corner combining 40kn
air consumption 120lmin
weight 300kgs
dimension 1800x1600x1300mm
machine advantage
* misplaced adopted in knife to rivet shaped materials without changing knife
* air pressure  drive without pollution
* quick lock device offer fast working speed
* knife easy to adjust with wide range.
