Contact SupplierWe offer pneumatic riveting machine.
Jm9q (pneumatic riveting machine)
characteristics:
■medium sized vertical style
■max. Processing dia.φ9mm
■pneumatic driven
■pressure by stepless regulation
■rotary part protected
■double-hand buttons or foot pedal
■set process time as will
■automatic and manual functions specification:
▲max riveting diameter ф 9mm ( solid steel rivet )
▲max riveting pressure 14kn
▲stroke 30mm
▲available working space 245mm
▲throat depth 160mm
▲riveting tool length 50mm
▲eccentric angle 4°
▲motive force pneumatic
▲workbench dimensions 260mm×200mm
▲power 0.55kw
▲physical size 700mm×500mm×1570mm
▲net weight 300kg
