Pneumatic Spot Welding Machine with Micro Controller

As improvements are constantly made in our machines the above specifications and dimensions are subject to modify without any prior notice

Company Information

Ask for more detail from the seller

Report incorrect details

“SHREE” Brand Pneumatic Spot Welding Machine WITH Micro Controller
		Pneumatic Type
Model	Unit	PCSW 15	PCSW 20	PCSW 25	PCSW 30
Rating @50% Duty Cycle	K.V.A.	15	20	25	30
Input Supply	Volts	380/440	380/440	380/440	380/440
Phase		2	2	2	2
	2 Line Of 3 Phase Supply
Insulation Class		A (CU.)	A (CU.)	A (CU.)	A (CU.)
Nominal Throat Clearance	mm	250	250	250	250
Throat Depth	cm	50	50	50	50
Max. Available Short Circuit Current	K. Amps	10	12	15	18
Max. Electrode Force @ 6 kg/cm²		450	450	450	450
Max.Upper Electrode Stroke	mm	50	50	50	50
Colling For Arms & Electrode	Water	Water	Water	Water	Water
Colling	Natural Air
Approx Dimension	Height	1620 mm	1620 mm	1900 mm	1900 mm
	Length	750 mm	750 mm	1040 mm	1040 mm
	Wight	500 mm	500 mm	510 mm	510 mm
Approx Weight 100% Copper		225 kg	255 kg	290 kg	320 kg
Approx Weight Semi – Copper		217 kg	245 kg	–	–
User Has To Provide The Following Services
Size Of Main Supply Copper Cable	MM²	16	20	25	25
Recommended Switch Rating	Amps	32	40	60	75
Delayed Action Fuse Rating	Amps	32	32	63	63
External Water Supply At Max. Temp. 30°c	Lit./Min	6	7	7	7
