conventional color : transparent, blue-green, ight-green, blue, light-opal, bronze(brown), etc.
thickness(mm) weight(kgm2) mini-bending
radius(mm) transparency(%) k value(wm2·k)
8 1.7 2400 71 2.56
10 2.0 3000 71 2.39
12 2.2 3600 70 2.30
14 2.4 4200 69 2.10
16 2.7 4800 68 2.00
18 3.0 5400 66 1.88
20 3.3 6000 63 1.69
technical parameters
impact strengh transparency specifc grevity coefficient of thermal expansion service temperayure heat conductivity
2.1jm-2.3jm 40%-80% 1.2gcm³ 0.065mmm°c -40°c—120°c 3.0-3.9wm²°c
tensile strengh flexural strengh modulus of elasticity effect of sound insulation tensile stress at break elongation at break
≥60nmm 100nmm² 2400mpa 10mm two laminates reduced 10db ≥65mpa >100%
