Polypropylene Film Capacitor

Detail information
cbb60 capacitor suitable used in electric motor and general purpose ac applications.with its good self-healing characteristic and long life, cbb60 capacitor is widely used for water pumps , cbb60 series are common used in refrigerators, air conditioner, electric fan, illuminating lamps, etc.
Product type cbb60 capacitor
capacitance range 4~30 uf
capacitance tolerance 5%
rated vottage 200vac 250vac 300vac 370vac 400vac 440vac 450vac 500vac 600vac 630vac
rated frequency 50 60 hz
operating temperature -40~+70+85
safety protection p0
testing voltage t-t:2.0 un60s
operating life classb classc
insulation resistance >=3000s
standard iec60252 gbt3667-2008
model cbb65 cbb60 cbb61
material metallized polypropylene metallized polypropylene metallized polypropylene
filling oil oil resion resion
can aluminum plasticaluminum plastic
capacitance range 3~120uf 4~30uf 1~16uf
voltage range 200~630vac 200~630vac 200~630vac
security level p1p2 p0 p0
operating temperature -40~+70+85 -40~+70+85 -40~+70+85
why choose anhui safe company ?
1.)as a national high-tech enterprise,we have 22 years exprience in capacitor industry,25 industry patents and a number of invention patents.
2.)to ensure the product quality and consistency,we have obtained the iso 9001 quality system certificate and cqc product certificate.
3.)we have modern factories and purification plant,the world first-class production equipment and the technical team consisted of a number of experts.
