Polyurethane Foaming Machine

Buy Polyurethane Foaming Machine from Yingkou Sanxing, the most renowned manufacturer, supplier and exporter of roll forming machines in Yingkou, Liaoning. Our product ensures even coating onto various surfaces using an air-pressurized spray gun. Our engineers ensure right measurements for precision.
More about Polyurethane Foaming Machine : SXPU, our high-pressure polyurethane spray equipment has a separate heater and the spray gun with non-solvents washing makes it easy to maintain.
Benefits :

• Flexible
• Compact
• Light-weight
• Durable

Standard Configuration :

• Mainframe : 1 set
• spray gun : 1 set
• Hearting and preserved pipe : 15m
• Connecting pipe fir spray gun : 1.5m
• Transfer pump : 2 sets


Technical Parameter :

• Ratio of raw materials : 1:1 (fixed ratio)
• Viscosity range of raw materials : 200-1000 CPS(under working temperature)
• Output : 4~8kg/min
• Heating device power for material : 1250 W x2
• Heating power for pipe heating preservation : 2000 W
• Total power : 4500 W
• Power source : 220V/50Hz/single
• Air source requirements :  0.5-0.8Mpa(70-120psi)≥0.9m3/min
• Single material output output pressure : 5-10 Mpa
• Volume : 800x700x1250(mm)
• Weight : 130kg


Features :

• The high pressure polyurethane insulation painting machine is used for professionals to spray painting for architectural coatings.
• It sprays even coating of polyurethane onto surfaces with an air-pressurized spray gun.
• The pump and the spray gun have the right measurement to avoid over-painting, keeping precision and speed even when temperature, pressure or viscosity alterations occurred.


SXPU the high-pressure polyurethane spray equipment. The parts of the equipment are accurate making sure the pressure is enough for mixing the double component materials together. It has the separate heater which is 1250 watt and provides the reliable heat source for the raw materials solving the problems of the viscosity of the materials. The 15-meter insulated pipe with heating guarantees that there will no heat losses for the heated materials. The system of spray gun with non-solvents washing makes the machine easy to operate and maintain.
It is widely used in different kinds of areas such as refrigerator warehouse heat preservation, building external wall, roof water-proof and heat preservation, gymnasium, motorcar and ship, air conditioner adiabatic, and solar water heater and so on.

Features of spray gun : Foam spray gun is absolutely reliable with flexible cooperation, and it is compact in structure, less easy-worn parts, light in weight , convenient in operation and durable in lifetime.
