Battery Portable Carbon Dioxide Purity Analyzer, Color : Grey

The Portable Carbon Dioxide Purity Analyser have been design especially for cylindrical and power station to check theCarbon dioxidePurity. The Analyzer is supplied in robust and reliable construction having Li-IONE rechargeable battery with 6 Hour of continuous operation. The integral Pump, Needle valve and Flow meter are used to control the sample through the analyzer during the monitoring of alternator gases. Features Simple Low Cost maintenance Microcontroller based embedded intelligent.

Specification:

• Principle Thermal Conductivity and NDIR (Non dispersive Infrared )
• Range %V/V Resolution 0.1 Unit or 1 Unit (Application based) Sampling Method Auto Suction or Direct Plug In
• Display 128 X 64 Graphics LCD
• Alarm Two Levels Low High Visual and Audible
• Power Source Built in Lithium Rechargeable battery
• Accuracy /2%
• Response Time Data Storage 5000 or 10000
• Computer Interface RS 232, USB,RS485
• Sensor Life 4-5 Years
• Operating Time 6 8 hours
• Environmental Temperature 15 degree Celsius
• Humidity Atmosphere Pressure 86- 106Kpa
• Housing High Impact Plastic
• Dimension in mm 200 (W) X 120 (H) X 185(D)
• Weight 1.5 KG
• Warranty One Year

Application:

• Hydrogen Cooled Alternators Turbine
• Hydrogen Analysis MAP (Food Gas Packaging)
• Gasification Syngas
• Metal Heat Treatment Plant
• Laboratories Institutions Treatment
• Process Chemical Industries
• Petrochemical Pharmaceutical Industries.
